Square battery 36 V – 11.5 Ah / 400 Wh

Features:

Dimensions of the 400 Wh electric battery: 8cm x 20.5cm x 7cm

Panasonic or LG 36 V Li-ion cells

Weight of the electric battery 400 Wh: 2,1 Kg

Sold with fireproof bag + extension cable (1,40 m) + charger

All our batteries are assembled in France.

The 36 volt Li-ion batteries we offer are all compatible with the LIFT-MTB kit.

Simply define the capacity you need based on the types of current output you do.

Main specifications:

– Voltage: 36 Volt / Li-ion

– Available capacities: 8.7Ah (300 Wh) / 11.5Ah (400 Wh) / 14Ah (500 Wh) available in flat or square or 17Ah (600 Wh)

– Dimensions / Weight : From 1.6 kg to 3.2 kg. see table

– Charger (included in the price): 2 Ampere charge intensity, 220 Volts power supply, euro plug.

– Service life: 800 cycles (16,000 km to 55,000 km depending on capacity)

– Estimated minimum autonomy: 20 to 70km and 500 to 1750 of D+ (see table.)

– The batteries are not waterproof!

-Fireproof transport bag to protect the battery and secure the charge.

– Other: Sold with 1.35 meter power cable to connect to the motor. (included in the price)

All our batteries are systematically checked on the test bench.

If a battery is not available, the manufacturing time is about 1 week, for more info contact us.

– Technology:

High discharge capacity with LG or PANASONIC cells, equipped with a BMS (Battery Management System) that regulates the discharge and charge to preserve its life.

–Minimum voltage allowed by the BMS: 27,5 V / Maximum voltage allowed by the BMS: 42 v

–Ideal charging temperature: 0°C to 42°C / Ideal discharge temperature: – 5°C to 42°C / Ideal storage temperature: 10°C to 30°C

– Allowable continuous discharge current: 30 Amps / Allowable peak discharge current: 60 Amps
